The durable and lightweight Storm 27.5 provides simple upkeep and operation to help young riders find the best line and stop on a dime.
Storm 27.5’s lightweight, durable aluminum frame and size-specific fork travel of 100mm combine with a simple, lightweight drivetrain, quality mechanical disc brakes, and optimized fit for riders from 4’2” to 4’8”, building and a love for dirt that’ll last a lifetime.
Component | Specification |
---|---|
Frame | Aluminum, Tig Welding, 10x135mm QR, Tapered HT |
Fork | Suntour XCT-30 DS Coil, 100mm, 46mm offset, 9x100 QR |
Rear Shifter | Shimano Cues SL-U4000, 9-speed |
Rear Derailleur | Shimano Cues RD-U4000, 9-speed, GS |
Crankset | Prowheel Alloy, 30T, 155mm |
Bottom Bracket | Cartridge, ST 73mm, 113mm axle length |
Cassette | Shimano Cues CS-LG300-9, 9-speed, 11-46T |
Chain | KMC Z9 |
Front Brake | Tektro HD-M276, Resin pads |
Front Brake Rotor | Tektro, 160mm rotor, 6-bolt |
Rear Brake | Tektro HD-M276, Resin pads |
Rear Brake Rotor | Tektro, 160mm rotor, 6-bolt |
Brake Levers | Tektro HD-M276 with Jr Lever |
Handlebar | 6061 Alloy DB 6.1, 720mm, 30mm rise |
Stem | Alloy 50mm Length, 31.8mm Clamp |
Seatpost | Alloy 31.6mm, 300mm length |
Headset | Zero Stack, 1-1/8" Steer, ZS44/28.6 |
Headset Spacer | 3x10mm |
Saddle | Norco Jr XC, Steel Rail |
Grips | DDK Lock-On, 139mm length |
Pedals | Nylon Flat Pedal |
Seatpost Clamp | Norco Alloy QR, 34.9mm ID |
Front Hub | Formula DC-1420, 9x100mm QR, 32h, 6-bolt |
Rear Hub | Formula DC-1422, 10x135mm QR, HG, 32h, 6-bolt |
Rims | DP 27 Rims, 27mm ID, 32H |
Front Tire | Maxxis Forekaster, 27.5x2.25", Wire |
Rear Tire | Maxxis Forekaster, 27.5x2.25", Wire |
Spokes/Nipples | Stainless Steel, 14g |
