Charge harder. Go faster.
From commanding the clock to holding your own on weekend rides. This bike is purpose-built to go fast and demolish steep trails. Its total enduro capabilities can help you secure that “top step” and tackle demanding group rides with confidence. With so much capability in your corner, it’s time to push limits, climb faster, and charge. Enduro lives at Altitude.
NEW SUSPENSION DESIGN!
| Frame | FORM™ Alloy | Full Sealed Cartridge Bearings | BSA Threaded BB | Internal Cable Routing | 2-Bolt ISCG05 Tabs | RIDE-4™ Adjustable Geometry | 160mm Travel |
| Fork | Fox 38 Float EVOL GRIP Performance Series 170mm | 27.5 = 37mm Offset | 29 = 44mm Offset |
| R / Shock | Fox Float X Performance | Sealed Bearing Eyelet | 40x10mm F Hardware | SM = 210x55mm | MD – LG – XL = 230x60mm | Size-Specific tune in FAQ |
| Headset | FSA ZS56|66 Reach Adjust | 0mm Cups Installed | +/- 5mm Cups Included | Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race |
| Stem | Rocky Mountain 35 AM | 5° Rise | All Sizes = 40mm |
| Handlebar | Rocky Mountain AM | 780mm Width | 38mm Rise | 9° Backsweep | 5° Upsweep | 35 Clamp |
| Grips | ODI Elite Pro Lock On |
| Brakes | Shimano SLX Trail 4 Piston | Metal Pads |
| F / Rotor | Shimano RT64 203mm |
| R / Rotor | Shimano RT64 203mm |
| Shifters | Shimano SLX |
| R / Derailleur | Shimano XT |
| Crankset | Race Face Aeffect Cinch | 32T | 24mm |
| Bottom Bracket | Shimano Threaded BBMT501-B |
| Cassette | Shimano Deore 10-51T 12spd |
| Chain | Shimano M6100 |
| F / Hub | Rocky Mountain SL Sealed Boost 15mm |
| R / Hub | Shimano XT Boost 148mm |
| Spokes | DT Swiss Competition 2.0/1.8/2.0 |
| Rims | WTB ST i30 TCS 2.0 Tubeless | 32H |
| Rim Tape | Tubeless Ready – Tape / Valves Incl |
| F / Tire | Maxxis Assegai 2.5 WT 3C MaxxGrip EXO+ |
| R / Tire | Maxxis Minion DHR II 2.4 WT 3C MaxxTerra DD |
| Seatpost | X Fusion Manic Alloy 30.9mm | Shimano MT500 Remote | SM = 150mm | MD = 170mm | LG – XL = 200mm |
| Saddle | WTB Volt Race 142 |
