The Torrent DH is built for riders who live for lift service, shuttle laps, and the feeling of dropping into a trail that pushes back. 200mm of travel in a straight up, no-nonsense package made to take a beating and keep coming back for more. It has a tough aluminum frame with size-specific geometry designed around dual crown forks and a mixed wheel setup — giving you the confidence to corner harder, brake later, and ride longer without worrying about anything but the next lap.
| Frame | Aluminum Frame, 200mm Travel, UDH, Ride Aligned™ |
| Fork | RockShox BoXXer Select D2, 200mm Travel, 52mm Offset |
| Rear Shock | RockShox Vivid Air Base, 225×75mm TR |
| Shifter | SRAM GX DH, 7-speed |
| Rear Derailleur | SRAM GX DH, Mid Cage |
| Crankset | Praxis Cadet DH9, 36T, 165mm (S3) |
| Bottom Bracket | Praxis M30 BSA Threaded, 83mm |
| Cassette | SRAM PG-720 DH, 11–25T, 7-speed |
| Chain | SRAM PC-1110, 11-speed |
| Chain Guide | MRP G5, 34–38T |
| Front Brake | SRAM Maven Base |
| Front Rotor | SRAM Centerline A2, 200mm |
| Rear Brake | SRAM Maven Base |
| Rear Rotor | SRAM Centerline A2, 200mm |
| Handlebar | RaceFace Chester, 800mm × 35mm Rise (S3) |
| Stem | RaceFace Chester Direct Mount, 50mm |
| Grips | RaceFace Chester, 31mm |
| Saddle | SDG Patriot |
| Seatpost | Norco Alloy, 31.6mm, Rigid |
| Front Hub | Novatech, 20×110mm Boost |
| Rear Hub | Formula DHT-148, 12×148mm Boost |
| Rims | WTB ST Tough TCS 2.0, 30mm, 32H |
| Front Tire | Maxxis Assegai 29×2.5" |
| Rear Tire | Maxxis Minion DHR II 27.5×2.4" |
| Complete Bike | 17.94 kg (39.52 lb) |
| Size Measured | S3 |
| Measurement | Size 1 | Size 2 | Size 3 | Size 4 | Size 5 |
|---|---|---|---|---|---|
| Wheel Size | 29"/27.5" | 29"/27.5" | 29"/27.5" | 29"/27.5" | 29"/27.5" |
| Travel (F/R) | 200/200 | 200/200 | 200/200 | 200/200 | 200/200 |
| Reach (mm) | 420 | 440 | 460 | 480 | 500 |
| Stack (mm) | 632 | 637 | 638 | 642 | 647 |
| Head Tube Angle (°) | 63.5 | 63.5 | 63.5 | 63.5 | 63.5 |
| Fork Offset (mm) | 52 | 52 | 52 | 52 | 52 |
| Seat Tube Length (mm) | 390 | 390 | 400 | 415 | 415 |
| Effective Seat Tube Angle (°) | 78.5 | 78.5 | 77.5 | 77.0 | 76.5 |
| Rear Centre / Chainstay (mm) | 430 | 435 | 440 | 445 | 450 |
| BB Drop F/R (mm) | 22 / 2 | 22 / 2 | 22 / 2 | 22 / 2 | 22 / 2 |
| BB Height (mm) | 352 | 352 | 352 | 352 | 352 |
| Horizontal Top Tube (mm) | 576 | 589 | 616 | 638 | 661 |
| Wheelbase (mm) | 1212 | 1240 | 1272 | 1299 | 1327 |
| Standover Height (mm) | 689 | 689 | 691 | 697 | 698 |
| Head Tube Length (mm) | 100 | 105 | 110 | 115 | 120 |
| Trail (mm) | 52 | 52 | 52 | 52 | 52 |
| Recommended Dropper | – | – | – | – | – |
| Max Post Insertion (mm) | 200 | 200 | 212 | 226 | 226 |
| Stem Length (mm) | 50 | 50 | 50 | 50 | 50 |
| Crank Length (mm) | 160 | 160 | 165 | 165 | 165 |
| Tire Size | 2.35"–2.5" | 2.35"–2.5" | 2.35"–2.5" | 2.35"–2.5" | 2.35"–2.5" |
| Water Bottle Compatible | No | No | No | No | No |
